Features

• High chemical resistant
• No air pollution, maintenance free
• Quiet and low vibration
• Thermal protection device
• International safety certification: CE certification

Applications

• Vacuum filtration
• Gel electrophoresis
• Solid-Phase extraction (SPE)
• Solvent purification

Specification (110V, 60Hz)

• Max. power: 90 W
• Max. current: 1,1 A
• Max. vacuum: -670 mmHg
• Max. flow rate: 38 l/min
• Motor rotation: 1700 RPM
• Horse power: 1/6 HP
• Noise level: 50.0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 7,0 kg
• Dimension (L x W x H): 26,7 x 11,2 x 18,1 cm

Specification (220V, 50Hz)

• Max. power: 90 W
• Max. current: 0,5 A
• Max. vacuum: -670 mmHg
• Max. flow rate: 33 l/min
• Motor rotation: 1450 RPM
• Horse power: 1/6 HP
• Noise level: 50.0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 7,0 kg
• Dimension (L x W x H): 26,7 x 11,2 x 18,1 cm

• Product datasheet (pdf, 437KB)
