EOSi

EOSi range is a new generation range of quiet, oil-sealed rotary screw vacuum pumps.

Features and Benefits

  • Oil-sealed rotary screw vacuum pumps,
  • Increased efficiency,
  • Improved productivity,
  • Intelligent control,
  • Low cost of ownership,
  • Quiet operation,
  • Reduced environmental impact.

Applications

  • Food freeze drying,
  • Altitude simulation,
  • Drying,
  • Load lock,
  • Pipeline drying,
  • Central vacuum systems,
  • Pneumatic conveying,
  • General packaging,
  • Plastics (e.g. bath tubs, shower trays, white goods internals),
  • Packaging materials (e.g. thermoformed parts),
  • Lamination,
  • Meat packaging (flat, vacuum packs, controlled atmosphere packaging),
  • Roof tile and brick manufacture,
  • Food cooling,
  • General evacuation duties,
  • Coating.
Technical data EOS 350i EOS 585i EOS 730i EOS 900i EOS 1300i EOS 1600i EOS 1900i
Peak pumping speed (m3/h) 400 560 730 900 1250 1590 1810
Ultimate vacuum (mbar) 0,35 0,35 0,35 0,35 0,35 0,35 0,35
Inlet connection DN80 DN80 DN80 DN80 DN150 DN150 DN150
Outlet connection DN60 DN60 DN60 DN60 DN100 DN100 DN100
Shaft power (kW) 5,5 7,5 11 15 22 30 37
Permissible ambient temperature (°C) 0 - 46 0 - 46 0 - 46 0 - 46 0 - 46 0 - 46 0 - 46
Noise level range (dB(a)) 51 - 65 51 - 65 51 - 73 51 - 76 65 -75 65 - 79 65 - 80
Oil capacity (l) 16 16 16 16 40 40 40

Dimensions (mm)

L

W

H



1266

934

1083



1266

934

1083



1266

934

1083



1266

934

1083



1420

1590

1470



1420

1590

1470



1420

1590

1470

Weight (kg)

500 500 510 520 1058 1058 1073
