Features

• Special design for large number samples
• Light and handy aluminum design
• Magnetic filter holder is included
• 4 liter PP waste bottle with drain

Applications

• Filtration for suspended solid test
• Filtration for microbiology test
• General laboratory filtration

Specification (110V, 60Hz)

• Max. flow rate: 37 l/min
• Max. vacuum: -680 mmHg
• Waste bottle: 4000 ml, made of PP with drain
• Number of branch: 3
• Filter diameter: 47 mm
• Funnel capacity: 300 ml
• Effective filtration area: 13,1 cm²
• Hose barb: 5/16 inch (8 mm)

Specification (220V, 50Hz)

• Max. flow rate: 34 l/min
• Max. vacuum: -680 mmHg
• Waste bottle: 4000 ml, made of PP with drain
• Number of branch: 3
• Filter diameter: 47 mm
• Funnel capacity: 300 ml
• Effective filtration area: 13,1 cm²
• Hose barb: 5/16 inch (8 mm)
