Features

• No pollution, maintenance free
• Quiet and low vibration
• Thermal protection device
• Air outlet filter device
• Certification: CE certification, CSA certification

Applications

• Aeration
• Pressure filtration

Specification (110V, 60Hz)

• Max. power: 147 W
• Max. current: 1,5 A
• Max. pressure: 100 psi (w/o moisture trap)
• Max. pressure: 80 psi (w. moisture trap)
• Max. flow rate: 27 l/min
• Motor rotation: 1700 RPM
• Horse power: 1/6 HP
• Noise level: 52.0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 5,2 kg
• Dimension (L x W x H): 29,8 x 14,3 x 17, 2 cm

Specification (220V, 50Hz)

• Max. power: 125 W
• Max. current: 0,6 A
• Max. pressure: 100 psi (w/o moisture trap)
• Max. pressure: 80 psi (w. moisture trap)
• Max. flow rate: 25 l/min
• Motor rotation: 1400 RPM
• Horse power: 1/6 HP
• Noise level: 52,0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 5,2 kg
• Dimension (L x W x H): 29,8, x 14,3 x 17,2 cm

• Product datasheet (pdf, 404KB)
