Features

• Save time
• Suitable for GL45 storage bottle
• Patent, No. M508321
• High chemical ressistant
• No air pollution, maintenance free

Applications

• Ideal for the purification of organic, corrosive liquid such as solvent (mobile phase) for HPLC analysis

Specification (110V, 60Hz)

• Max. power: 70 W
• Max. current: 0,8 A
• Max. vacuum: 670 mmHg
• Max. flow rate: 20 l/min
• Motor rotation: 1700 RPM
• Horse power: 1/8 HP
• Noise level: 50,0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 5,0 kg
• Dimension (L x W x H): 20,3 x 11,2 x 20,9 cm

Specification (220V, 50 Hz)

• Max. power: 60 W
• Max. current: 0,32 A
• Max. vacuum: 670 mmHg
• Max. flow rate: 18 l/min
• Motor rotation: 1450 RPM
• Horse power: 1/8 HP
• Noise level: 50,0 dB
• Hose barb: 5/16 inch (8 mm)
• Net weight: 5,0 kg
• Dimension (L x W x H): 20,3 x 11,2 x 20,9 cm

• Product datasheet (pdf, 246KB)
